ASME certificate sanitary ss304 ss316L stainless steel Stirrer tank reactor 3 three jacket
Why choose us?
We have focused on this area for over 15 years, and the boss of Jheten is a professional engineer who has 20 years' experience in what we are concentrating on!
Application
1). unsaturated resins, alkyd resins, acrylic resins, polyurethane resins and other complete sets of production equipment.
2). lotion, white latex, PU glue, adhesive sets of production equipment.
3). waste silica gel pyrolysis, recycling equipment.
4). paint sets of production equipment.
5). complete sets of all kinds of fine chemical production equipment.
Specifications
1). The chemical reacting equipment.
2). Widely used in making resins, adhesives, paints, cosmetics, pharmaceuticals and other chemical productions.
3). Mechanical seal.
4). Inverter for frequency control.
5). Jacketed type, outer-pipe type, outer-inner-pipe type.
6). Heated by oil, water, steam or electric.
7). Three-layers paddle style, made of stainless steel.
8). Consists of body, gears, mixing devices, heating devices, cooling devices, seal composition.
9). Equipped with distillation column, condenser, water separator, collecting cans, filters ect.
10). Supply complete production line, as well as productin technology!
Product paremeter
1,The parameters above are standard ,any special requirement, please put forward.Note:
2,Interlayer’s working pressure ≤0.15Mpa,can be made according to special require.
3,Parameters like material, working pressure, working temperature and any special request should be noted.
4.Various agitator types
| Capacity | 500 L | 1000 L | 2000 L | 3000 L | 4000 L | 5000 L |
| Motor Power(with gearbox) | 4 kw | 5.5 kw | 7.5 kw | 7.5 kw | 7.5 kw | 11 kw |
| Material | 304 Stainless Steel (Inner) |
| Carbon steel (Outer) |
| Inner plate thickness | 6 mm | 6 mm | 8 mm | 8 mm | 8 mm | 10 mm |
| Outer platethickness | 5 mm | 6 mm | 6 mm | 8 mm | 8 mm | 8 mm |
| Heating way | Thermal Oil heating |
| Inner dimeter | 1000 mm | 1200 mm | 1400 mm |
Competitive Advantage:
Jhenten is a professional manufacturer of tank equipment more than 30years .
Jhenten can produce cartridge filter housing ,bag filter housing ,water filter housing ,industrial filter housing ,high
flow filter housing etc
Currently Jhenten already obtained CE,ISO9001 ,D1 D2 pressure vessel fabricate certificate and we also are the
stable supplier of Veolia ,SIEMENS ,IWAI ,SPX , Mitsubishi
Transport & packaging
