easy clean inox 304 316L 500L react tank for cosmetic vaccum tank reactor pressure tank
Configuration of tank:
1) Manhole
2) CIP cleaner
3) Adjustable triangle bracket
4) pressure gauge.
5) Thermometer
6) Liquid lever meter and controller
7) Eddy-proof board
8) Dismountable Inlet assembly
9) Sanitary breathing cover
10) mixer: paddle, anchor, or spiral mixer (optional)
11)three-layer, PU insulation or single-layer (optional)
12)reducer(optional)
13)motor:ABB, Siemens, SEW (optional)
14)Inverter(optional)
Product paremeter
1. Material: SUS 304 and/or SUS 316.
2. Single layer or jacketed.
3. Heating: Electric, steam, hot water and gas heating optional.
4. Outer casing surface: Mirror polishing / 2B / mat; Inner surface (bladder and tank): Mirror polishing
5. Insulating layer: Warm-keeping layer of polyurethane foaming ensures temperature variation of the liquid product in the tank controlled at the minimum.
6. Liquid level gauge: Optional.
7. Thermometer: Optional.
8. Sample valve: Optional.
9. Agitation device: Paddle, Anchor, or spiral agitator (optional).
10. CIP cleaning: T-shaped 360° Rotational CIP cleaning ball.
11. Man-hole equipped from jst machinery
| volume | 300L | 400L | 500L | 600L | 800L | 1000L | 1500L | 2000L | 3000L |
| Tank diameter(mm) | Φ800 | Φ800 | Φ900 | Φ1000 | Φ1000 | Φ1000 | Φ1200 | Φ1300 | Φ1600 |
| Tank height(mm) | 600 | 800 | 800 | 800 | 1000 | 1220 | 1220 | 1500 | 1500 |
| Motor power(kw) | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.5 | 2.2 | 3 |
| Mixing speed(rpm) | 36r/min |
| Working pressure | ≤0.09Mpa |
| Working temperature | <100°C |
| Basic accessory | Sanitary man hole,cleaning ball,safety,pressure gauge |
Application:
It can be used as the reacting tank in paint, emulsion, adhesive, petroleum can be widely used in petroleum, chemical,
, pesticide, dye, medicine and food industry. Used to achieve curing, hydrogenation, alkylation, polymerization, condensation process. Food procession, cosmetics production, chemical industry, dyeing and printing facilities, essence and fragrant substance production, fine chemical industry, emulsification of diesel oil and pitch.
Our Service
Per-sale service:
♦ We can supply you all the details you need.
♦ We can provide drawings according to your requirements.
♦ We can also make customized products according the drawings.
After-sale service:
♦ We provide long-term after-sale service.
♦ If necessary,our technicians can go to debug the machine with air ticket,visa,accommodation and labor cost provided by your party.
♦ You can consult any relevant questions by phone,E-mail and communicate online.
Packaging
The reactor will be packed by standard wooden case.
The reactor can be shipped by sea or air,the detail shipping term can be discussed.
