ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory & Medical

Name: ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory amp Medical
Brand: Jhenten
Price: 20 USD

China ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory & Medical wholesale

Brand Name : Jhenten

Model Number : ZTLD-05

Certification : CE,ISO9001,ASME,

Place of Origin : China

MOQ : 1 PC

Price : USD20-100 pc

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30pcs per month

Delivery Time : 30 days

Packaging Details : wooden box or as customer's requirement

Material : ss304 ss316L

No.of cartridge : 5-6R 7R

Grade : FOOD

Surface : POLISH

MAX operate temp. : 110

Type : Flange clamp

standard : DIN/SMS/RJT/IDF/3A

Contact Now

ss304 ss316 sanitary filter housing cartridge with clamp for laboratory & Medical

Description:

Complete stainless steel structure
Made of 100% SUS304 or SUS316L
Wide chemical compatiblity
Can be used in acid and alkaline

Meet the GMP requirements: Electropolished, Smooth and Round corner design, no dead space

Complete stainless steel structure: Made of 100% SUS304 or SUS316L. Wide chemical compatiblity. Can be used in acid and alkaline solvents

Wide range of connections sizes and types,cartridge length for choice.

All kinds of liquid filtration system.

Specifications

1.Mirror Polish or electro polish Ra<0.3um ,Food-Grade
2.High Flow Rate
3.Factory Price
4.SGS certificate/CE/ISO9001

Product Name:	ss304 ss316 sanitary filter housing cartridge with clamp for laboratory & Medical
Cartridge housing Material:	ASTM304/316L
Cartridge Material:	PTFE/PE/NYLON/PP
Capacity:	0.5~25 t/h
Pressure:	filter 0.1~0.6 mpa; cartridge 0.42mpa,bounce-backed
Filter Seat:	1 core; 3 core;5 core; 7 core; 9 core; 11 core; 13 core; 15 core
Length:	10"; 20"; 30"; 40"(250; 500; 750; 1000mm)
Connections:	plugged(222,226)/flat nib style
Cartridge presicion:	0.1~0.6μm
Internal surface:	Ra 0.2μm
Hole dia:	0.1μm; 0.22μm;1μm;3μm;5μm;10μm;
Advantages:	high presicion,fast speed,low adsorption,no media fall off;acid resistant,easy operation
Features:	small volume,lightweight,large filter area,low jam,Non-pollution,good chemical and calorific stabilities.
Application Scope:	Widely used in the fields of pharmacy,winery,beverage,chemical,etc
Design:	users should configure different material and type of filter for different purpose and medium.For example,for GMP pharmacy water,we use 5μm and 0.1μmfolded sleeve filters tandem.Another one,in ferment industry,before inputting air,this filter can annihilate the bacteria,it can also dispose the exhaust till thegas reaches HIM standard.
Packaging Details:	Bubble pack for each. Outside packing are carton or plywood cases. Or as per the request of customers.
Delivery details:	Usually within 20 days after receiving T/T down payment.

APPLICATION:

* Food & Beverage Industries
* Electronics Industries
* Chemical Industries
* Pharmaceutical Industry

ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory & Medical

Package & Delivery

ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory & Medical

Contact:

ss304 ss316 stainless steel housing omnipure water filters cartridge with clamp for laboratory & Medical

Product Tags:

Pool Filter Housing

Sock Filter Housing
