50L-10T Sanitary liquid mixing tank mixing vessel Cold and hot mixing tank
Description:
Used as mixing tank, blending tank etc.
Ideal in fields such as foods, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc.
Main adopts stepless timing device which reduce babble occur under low temperature and high
viscosity condition less air bubble will be formed
To produce liquid washing product
Finished products can be discharged by Disc-valve or suitable to all liquid wash products.
1). It is an indispensable device in daily chemical industry, such as the production of medicine,
pesticides, food, liquid soap, commodity, commodity, cosmetics, chemical shampoo, bath gel
and other mucus inter-mixed, dissolved, mixing stirring, it is an ideal equipment in daily chemical
industry.
2). The blending system adopts single-direction or double-direction wall scraping blending and
frequency conversion speed adjustment to satisfy production of different technological requirements.
Materials can be heated or cooled according to technological requirements.
3). The heating methods such as steam or electric heating can be selected according to custom
requirements.
Chemical Mixing Tank with 4).Various forms of blending vanes are suitable for production of different types of products.
Chemical Mixing Tank with Agitator Stainless Steel Mixing Tank
5). Made of imported SUS304 or SUS316L stainless steel. The tank body and pipe are subjected
to mirror polishing.
Chemical Mixing Tank with Agitator Stainless Steel Mixing Tank
6).Bottom installation type dispersing head and pipeline type emulsifying head are optional to
speed up dissolution and emulsification of materials. Chemical Mixing Tank with Agitator Stainless Steel Mixing Tank
7). The stainless steel electric control cabinet can completely supervise the operation of equipment,
and display such data as temperature and blending rotation speed etc. Chemical Mixing Tank with Agitator Stainless Steel Mixing Tank
8). OEM & ODM are welcome. We could do equipment according to your detail requirements.
| | 100L | 200L | 500L | 1000L | 2000L | 5000L | 10000L | 20000L |
| Diameter(mm) | 400 | 500 | 700 | 900 | 1200 | 1500 | 1800 | 2300 |
| Heigh(mm) | 2000 | 2300 | 2650 | 2900 | 3800 | 4480 | 5250 | 6550 |
| Inner pressure(Mpa) | 0.2 |
| Layer pressure(Mpa) | 0.3 |
| stirring paddle No. | 2 |
| Stirring speed(r/min) | 80 |
| Motor power(kw) | 0.55 | 0.75 | 1.1 | 1.5 | 3 | 5.5 | 7.5 | 7.5 |
| Cooling method | Layer calandria |
Jhenten Quality Control for Chocolate Melting Tank:
1.The raw materaial plate was anlysised by our material anlysier to assure the quality
2.The welding is argon arc weld(TIG) to avoid plate's oxidized
3.After welding the the inner tank ,we will make a full water pressure test to check the welding joint .After welding the jacket ,the full water pressure test be done for jacket too
4.After finishing the surface finish ,our people will make a surface roughness testing to assure the Ra data
5.After agitator installment ,we will operate it to assure the function is good.
FAQ:
1. Q: Does your company have any MOQ of your products?
A: No, We do not have MOQ requirement, For small orders we could deliver by courier.
2. Q: Does your company accept no-standard (customized) products?
A: Sure, As soon as you could provide drawings or details.
Packaging & Shipping
Our standard packing is plywood case,
Shipping method including: Courier (DHL, FEDEX etc), By Airline, By Sea
Price Term including: EXW, FCA, FOB, CIF.
