inox 304 316L stainless steel mixing QUICK melting tank for butter oil sugar chocolate
Specifications
Sugar melting tank are mainly suitable for dissolving white granulated sugar, also use to melt milk powder, starch etc powder or granular materials.It also play some functions as stirring,dissolving, heating( or cooling, use tap-water cooling), filtrating( strainer) and others.Fast melting speed, high efficiency, is the one of technology equipment for food, drink productions.
Sugar melting tank prepared for series of advantages like convenient to operate, corrosion resistance, powerful production ability, easy to clean and maintenance. External tank body is the stainless steel which was polished and processed to more bright and smooth of the surface of tank.
Suger Dissolving tank primarily put dissolved materials and cool water(or hot-water) in tank , and then steam inlet inter-layer to reach the effects through heated dissolving.
1. This tank is suitable for melting granularity sugar into syrup, involve in food industry , pharmaceutical etc. some food as confetti, sprinkles , and tablet need to coat suagr , these will need to sugar melting tank . Because this product need add syrup into it to polish.
2. Top stirring, bottom discharge hole, easy to operate, convenient for cleaning
3. With four legs as support, it is more stablity.
4. It is very porpular for use for food industry, pharceutical plant and etc.
5. triple -layer, the inner layer is touch materials, the middle layer is heating, and the outer -layer is insulation.
Application:
1.Food process such as juice ,beverage ,milk and pure water ,sugar so on
2.Pharmaceutic process field
3.Chemical industry
4.Bioengineering
Product paremeter
| sugar melting tank |
| Material: | SS304 or SS316L or Duplex stainless or 904L |
| Design Pressure: | -1 -10 Bar (g) or ATM B9 |
| Work Temperature: | 0-200 °C |
| Volumes: | 50~30000L |
| Construction : | Vertical type or horizontal |
| Jacket type : | Dimple jacket, full jacket, or coil jacket |
| Structure : | Single layer vessel, vessel with jacket, vessel with jacket and insulation |
| Heating or cooling function | According to the heating or cooling requirement , the tank will have jacket for requried function |
| Opitional Motor: | ABB, Siemens, SEW or Chinese brand |
| Surface Finish: | Mirror Polish or Matt polish or Acid wash&pickling or 2B |
| Standard components : | Manhole,sight glass , cleaning ball |
| Optional components : | Vent filter, Temp. Gauge, display on the gauge directly on the vessel Temp sensor PT100, digital display on the control cabinet by instrument Temp sensor with control for heating and cooling Level gauge with digital display on the control cabinet by instrument Load cell Valves |
| Applications: | Wine, Beer Juices Food & Beverage Pharmaceutical Biotechnology & Laboratory Medical &Medical Device Chemical Industry Painting Industrial |
The detailed design is according to site dimension and technical requirement to design.
Competitive Advantage:
Jhenten is a professional manufacturer of tank equipment more than 30years .
Jhenten can produce cartridge filter housing ,bag filter housing ,water filter housing ,industrial filter housing ,high
flow filter housing etc
Currently Jhenten already obtained CE,ISO9001 ,D1 D2 pressure vessel fabricate certificate and we also are the
stable supplier of Veolia ,SIEMENS ,IWAI ,SPX , Mitsubishi
Transport & packaging
