Brand Name : Jhenten
Model Number : ZTFV-1
Certification : CE , ISO9001 , SGS , TUV , ASME U Stamp
Place of Origin : China (Zhejiang)
MOQ : 1 PC
Price : Can negotiation
Payment Terms : L/C, T/T, Western Union, MoneyGram
Supply Ability : 300 sets/month
Delivery Time : 25 workdays
Packaging Details : plywood packing or according to customer requirements
Material : SS304 or SS316L or Duplex stainless or 904L
After-sales Service Provided : Engineers available to service machinery overseas
Opitional Motor : ABB, Siemens, SEW or Chinese brand
Warranty : 1 year
Weight : 200~5000kg
Function : Fermentation
Standard : GMP Standard
Inner Surface : Ra≤0.6μm
1000L, 2000L, 3000L Stainless Yogurt Fermentation Tank Mirror Polished
Inner surface:stainless steel sheets,polished to sanitary standard.
Exterior surface:copper cladding
Thickness:1.5-3mm
Heating method:gas,steam generator,directly fire,electricity.
Mechanical agitator
Equipped with fittings and pipelines.
Stainless Fermentation Tank Main parameters:
Item | Volume | A | B | C | D | E | F | G |
ZTFV-04 | 400L | 950 | 1090 | 500 | 750 | 165 | 320 | 2220 |
ZTFV-06 | 600L | 950 | 1090 | 500 | 1000 | 165 | 320 | 2470 |
ZTFV-08 | 800L | 1100 | 1240 | 500 | 1030 | 175 | 351 | 2561 |
ZTFV-1 | 1000L | 1270 | 1410 | 500 | 1030 | 195 | 386 | 2636 |
ZTFV-1.5 | 1500L | 1270 | 1410 | 500 | 1390 | 195 | 386 | 3096 |
ZTFV-2 | 2000L | 1400 | 1540 | 500 | 1460 | 225 | 413 | 3223 |
ZTFV-3 | 3000L | 1600 | 1740 | 500 | 1670 | 255 | 455 | 3505 |
ZTFV-4 | 4000L | 1850 | 1990 | 500 | 1700 | 305 | 506 | 3636 |
ZTFV-6 | 6000L | 1850 | 1990 | 500 | 2470 | 305 | 506 | 4406 |
ZTFV-10 | 10000L | 2150 | 2315 | 500 | 2970 | 340 | 568 | 5268 |
ZTFV-15 | 15000L | 2450 | 2615 | 500 | 3400 | 360 | 631 | 5781 |
ZTFV-20 | 20000L | 2850 | 3015 | 500 | 3400 | 380 | 714 | 5884 |
Our service:
we will supply you with drawing before manufacturing.
we will firmly manufacture according to the drawing.
we will be in charge of installation.
we will send you our fittings for free if it is broken bt accident during 2 years
Stainless Fermentation Tank Application
![]() |
SS304 Stainless Fermentation Tank Yogurt Fermentation Tank Homogenizing Emulsification Tank Images |
