Matt Polish Basket Bag In Bag Out Filter Housing Cartridge Filter Housing

Name: Matt Polish Basket Bag In Bag Out Filter Housing Cartridge Filter Housing
Brand: Jhenten
Price: 1 USD

Brand Name : Jhenten

Model Number : ZTLF-16

Certification : CE ISO9001 ASME SGS

Place of Origin : China (Zhejiang)

MOQ : 1 PC

Price : Can negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 Set/Sets per Year

Delivery Time : 25 Days

Packaging Details : plywood packing or according to customer requirements

Material : SS304,316L

After-sales Service Provided : Engineers available to service machinery overseas

Gasket Material : EPDM PTFE Viton Silicon

Mesh's pore size : 10Mesh - 100Mesh

Connection standard : Clamp , Flange ， Screw thread

Inlet / Outlet dimension : 1" ， 1.5" , 2" , 2.5" , 3" , 4"

Warranty : 12 months

condition : new

Contact Now

Matt Polish Basket Type Filter For Plant Oil With EPDM Gasket Meet GMP Standard

Description:

Basket type filter is used for prefilter or middle filter,which removes particles, visible to naked eye. The filter media is stainless mesh for high pressure and temperature . Outside the filter mesh is covered with basket support to withstand pressure . Jhenten's basket type filter also can jacket and insulation layer for our customer who is required .

Product characteristics

1. Good filtering effect;
2. Accurate filtering;
3. Easy to change and clean ;
4. Easy to maintain;

5. Filter the big strains of solid impurities, and make sure the device run smoothly.
5. Safe to use, convenient to operate, widely to use.

Main data

Product Name:	Basket Type Filter
Body Material:	SS304/SS316L
Seal Material:	EPDM , VITON, PTFE, Sililone
Filter element:	Filter basket
Inner polish:	Ra<0.3μm
External polish:	Mirror polish/ Surface Drawing
Max working pressure:	1.0Mpa / 150PSI
Max Working Temperature:	130°C
Availably size:	ZTLF-16 (16M3/H) /ZTLF-25 (25M3/H)/ZTLF-45 (45M3/H)
Availably connection:	Clamp / weld / thread
Availably standard:	DIN/ ANSI/ ASME/ JIS /TS
Type option:	Single / duplex Type
Application scope:	Dairy,food, beverage, pharmacy, cosmetic, Chemical, etc, mainly used in edible oil, beverage and winery chemical industry.
Advantages:	High flow, sanitary grade, can protect all kinds of equipment.
Packaging Details:	Bubble pack for each. Outside packing are carton or plywood cases. Or as per the request of customers.
Delivery details:	Usually within 20 days after receiving T/T down payment.

Main parameters

Item	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)
ZTLF-16	810	425	294	275	75
ZTLF-40	1050	600	400	300	100

Cleaning Control

obtuse angles design on edge and corner
Surface polishing uniformly ,can provide polish inspection report
No gap and sunken
Seamless accessories and fitting

Why choose our filter?

1. Jhenten machine have sales department, engineering department, after sales department, weprovide one-stop service for you;
2. We are not competing for the price but the high quality and friendly service we competition
3. The salesman and engineer will listen to your requirements and the effect which you want to reach patiently, and tailored for you;
4. The after sales colleague will service for you from place an order to the actual production;
5.29 years of industry experience, industry leader;
6. Factory, office site visit.

Application
