ss316L SS304 stainless steel sanitary precise filter housing filter TOP Flange With Rotated Arm
Introduction:
Precise filters have a long history in Food and Beverage applications. They arose out of the need to package sheet-based depth filter technology in more user-friendly, modular closed systems, especially for small batch production or medium flow rate applications.Jhenten's lenticular filter housing can be suitable for international brand's filter disk with lower cost.The surface finish totally arrive sanitary grade requirement.
Stainless Steel Sanitary Precise filters Housings have surface finish of mechanical polish, making the housings ideal for demanding processes requiring high purity. The housings can be disassembled in all parts, eliminating possibility of retained particles and making more effective cleaning. The design of clamp closure advantages the housings with convenient operation and quick element change out. Manufactured by 100% stainless steel, the housings are competent to work in a wide range of critical applications.
Precise filters have a long history in Food and Beverage applications.
Specificatios:
| Name | Inner surface |
| Max Operate Pressure(MPA) | 1.0 |
| Max Operate Temperature (℃ ) | 110 |
| Pressure Tolerance on Weld | 0.85 |
| Corrosion by acid (mm) | 0 |
|
Item | No.of
Cartridges | A | B |
C |
D |
E |
| 20" | 30" | 40" | 20"" | 30" | 40" |
| ZTJM-15R | 15-18R | 1475 | 1775 | 1975 | 600 | 800 | 1050 | 300 | 200 | 400 |
| ZTJM-21R | 21R | 1520 | 1770 | 2020 | 600 | 800 | 1050 | 300 | 200 | 450 |
| ZTJM-24R | 24,27,30R | 1580 | 1830 | 2080 | 600 | 800 | 1050 | 300 | 200 | 500 |
| ZTJM-36R | 36R | 1580 | 1830 | 2080 | 600 | 800 | 1050 | 300 | 200 | 550 |
| ZTJM-42R | 42R | 1600 | 1830 | 2100 | 600 | 800 | 1050 | 300 | 200 | 600 |
| ZTJM-48R | 48-54R | 1595 | 1845 | 2095 | 600 | 800 | 1050 | 300 | 200 | 650 |
| ZTJM-60R | 60R | 1650 | 1900 | 2150 | 600 | 800 | 1050 | 300 | 200 | 700 |
| ZTJM-75R | 75R | 1705 | 1955 | 2205 | 600 | 800 | 1050 | 300 | 200 | 800 |
Filter Housing Operating Parameters
| Items | Parameters |
| Max Operate temperature | 150ºC |
| Max Operate pressure | 10bar |
| Corrosion by acid | 0 mm |
| Industrial sure tolerance on weld | 0.85 |
Application:
a. Wine
b. Beer
c. Juices
d. Vinegar
e. Soft Drink
f. Bottled Water
g. Aseptic Packaged Liquids
h. Pharmaceutical Liquids
Package & Delivery
We are READY, and you ?
